○ It is possible to drill hardened material (50 to 70HRC)
○ By Aqua Coating (PAT.P). which is wealthy in the lubrication with the work material and excellent to heat-resistance. So suitable for drilling hardened steel.
○ High stiffness and reduce vibration because of adoption of thick web and low helix.
High stiffness and reduce vibration because of adoption of thick web and low helix. So prevent sudden breakage from micro tipping
Drill : 4mm
Speed : 17.5m/min(1.400min-1)
Feed : 0.04mm/rev(56mm/min)
Depth : 10mm Through
Material : SKD11(60HRC)
Coolant : Emulsion
Drill : 6mm
Depth : AQUA ; 20mm Through
: Competitor ; 13mm Blind
Material : SKD11(60HRC)
Coolant : Emulsion
Conditions
Drill : 6mm
Speed : 50m/min(2650min-1)
Feed : 0.12mm/rev (320mm/min)
Depth : 12mm Blind
Material : SKD61 5(51HRC)
Coolant : DRY
Conditions
Drill : 6mm
Speed : 20m/min(1060min-1)
Feed : 0.05mm/rev (53mm/min)
Depth : 12mm Blind
Material : SKD11 (60HRC)
Coolant : Emulsion
